StarTech.com HDMI KVM Extender over IP Network - 4K 30Hz HDMI 2.0 and USB over IP LAN or Cat5e/Cat6 Ethernet Cable (100m/330ft) - Remote KVM Switch/Console Transmitter/Receiver Extender Kit

StarTech.com HDMI KVM Extender over IP - 4K 30Hz HDMI 2.0 & USB over IP LAN or CAT5e/CAT6 Ethernet (100m/330ft) - Remote KVM Switch/Console Transmitter/Receiver Extender Kit (SV565HDIP)
In stock
Only 3 left
Part Code:
SV565HDIP
£484.17 £581.00
Manufacturer:StarTech.com


KVM Console Extender Over IP | HDMI® | 4K @ 30Hz | 4x USB Ports | EDID Pass-ThroughThis HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.Supports UHD 4K 30HzThe HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.Hassle-Free InstallationWith a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.Versatile Configuration OptionsThe extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5 or CAT6 cabling up to 330 feet (100 meters).SV565HDIP is backed by a 2-year warranty and free lifetime technical support.The StarTech.com Advantage
More Information
Part Code: SV565HDIP
EAN 0065030877947
Specification
Technical details
Product colourBlack
On Screen Display (OSD)Yes
Maximum operating distance100 m
LED indicatorsYes
Hot keysNo
IP controlNo
USB hubYes
Sustainability certificatesRoHS
Video
HD type4K Ultra HD
Video bandwidth30 Hz
Maximum resolution3840 x 2160 pixels
Ports & interfaces
Number of microphone inputs2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
Audio connectionsYes
Headphone outputs8
HDMI ports quantity2
Ethernet LAN (RJ-45) ports2
DC-in jackYes
USB hubYes
USB 2.0 Type-A hub ports quantity2
Network
Ethernet LAN (RJ-45) ports2
Performance
Daisy chainNo
ChipsetASPEED - AST1520
HD type4K Ultra HD
Video bandwidth30 Hz
Maximum resolution3840 x 2160 pixels
Maximum operating distance100 m
Audio channels7.1
Design
Mean time between failures (MTBF)60000 h
Product colourBlack
LED indicatorsYes
Hot keysNo
CertificationCE, FCC, TAA, REACH
Housing materialSteel
Display
Built-in displayNo
On Screen Display (OSD)Yes
Power
Input current0.6 A
Output current1.5 A
Power plug typeType M
Compatible power plug typesAU, EU, JP, UK
Output voltage12 V
AC input voltage100 - 240 V
Power consumption (typical)18 W
External power adapterYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width117 mm
Depth130 mm
Height28 mm
Weight610 g
Package width365 mm
Package depth195 mm
Package height235 mm
Packaging data
Package width365 mm
Package depth195 mm
Package height235 mm
Packaging content
Rubber feetYes
Cables includedHDMI, LAN (RJ-45), Phone (RJ-11), USB
Quick installation guideYes
AC adapter includedYes
Certificates
CertificationCE, FCC, TAA, REACH
Logistics data
Master (outer) case width38.5 cm
Master (outer) case length49.5 cm
Master (outer) case height26.5 cm
Quantity per master (outer) case6 pc(s)
Other features
Maximum operating distance100 m
Hot keysNo
IP controlNo
Manufacturer StarTech.com
