StarTech.com Industrial 8 Port Gigabit PoE Switch - 30W - Power Over Ethernet Switch - GbE PoE+ Unmanaged Switch - Rugged High Power Gigabit Network Switch IP-30/-40 C to 75 C

StarTech.com Industrial 8 Port Gigabit PoE Switch - 30W - Power Over Ethernet Switch - GbE PoE+ Unmanaged Switch - Rugged High Power Gigabit Network Switch IP-30/-40 C to 75 C (IESC1G80UP)
In stock
Only 10 left
Part Code:
IESC1G80UP
£338.17 £405.80
Manufacturer:StarTech.com


Rugged PoE Switch | 30 Watts | IP-30 Aluminum Housing | Unmanaged | 8 Port

This industrial 8 port gigabit PoE switch features 30W of power and is designed to be installed in harsh environments and supports up to a total of 200W power outputs. Includes hardware for DIN rail or wall mounting.

For Demanding Environments Where No Fiber Connections Are Required

Using Cat 5e (or higher rated) Ethernet cabling, this Ethernet switch Provides up to 30W of PSE power per PoE port (PSE) to IEEE 802.3af (PoE / Type 1) and IEEE 802.3at (PoE+ / Type 2) PD devices like:

Cameras

Sensors

Wi-Fi Access Points

High total power budget with high PoE port count at a maximum of 30 watts per port, up to 200 watts max. Power provided in order of device connection; max 6 802.3at (30W) devices (180W total) at any time.

Truly Industrial for Devices That Must Function Under Harsh Conditions

Industrial features include:

Operating Temperature Range: -40 C to 75 C

IP-30 rated housing

Vibration, shock, and free-fall standard testing

This Ethernet switch supports additional features such as redundant power inputs, 2kV surge protection on RJ45 ports, and an MTBF of 500,000+ hrs (Telcordia/Bellcore) at 50°C, for long-term reliability.

The StarTech.com Advantage

- POWER OVER ETHERNET: Gigabit PoE Switch provides up to 30W of PSE power per PoE port to IEEE 802.3af (PoE) & IEEE 802.3at (PoE+)
- Use with devices like cameras & access points using Cat 5e/6
- TECH SPECS: 8 port GbE PoE switch
More Information
Part Code: IESC1G80UP
EAN 0065030889605
Specification
Ports & interfaces
Terminal block portYes
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity8
Technical details
Product colourBlack
Mean time between failures (MTBF)693764 h
Housing materialAluminium
Management features
Switch typeUnmanaged
Network
Cable types supportedCat5e,Cat6
Networking standardsIEEE 802.3af,IEEE 802.3at,IEEE 802.3x
Full duplexYes
Flow control supportYes
Auto MDI/MDI-XYes
10G supportNo
Data transmission
Jumbo frames9000
Switching capacity16000 Gbit/s
Jumbo frames supportYes
Certificates
CertificationCE, FCC, UL, ROhS
Design
Wall mountableYes
International Protection (IP) codeIP30
DIN rail mountingYes
Product colourBlack
LED indicatorsYes
Housing materialAluminium
CertificationCE, FCC, UL, ROhS
Performance
Buffer size128 KB
Mean time between failures (MTBF)693764 h
Indication
LED indicatorsYes
Power
Power consumption (max)206 W
Surge protection voltage2 kV
DC input voltage48 - 56 V
Surge protectionYes
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget200 W
Power over Ethernet (PoE)Yes
Weight & dimensions
Width105 mm
Depth142 mm
Height39.6 mm
Weight536 g
Packaging data
Terminal block includedYes
Quick start guideYes
Package width211 mm
Package depth162 mm
Package height64 mm
Package weight781 g
Logistics data
Master (outer) case width35.5 cm
Master (outer) case length34.5 cm
Master (outer) case height22.5 cm
Quantity per master (outer) case10 pc(s)
Other features
Terminal block portYes
Packaging content
Terminal block includedYes
Quick start guideYes
